80cm width

Smart slider

An intuitive and very simple operating concept for all appliances: the Smart Slider makes every setting perfect.

Combi induction

Two induction cooking zones can be switched together to create one single cooking zone, thereby allowing the use of very large pots and pans. Of course, the two large cooking zones can also be used separately.

Touch Control

Precise, innovative and very user-friendly: gently touching the Touch Control buttons is enough to select the desired setting.

Boost function

No long heat-up times: the right cooking temperature is reached in seconds with the boost function.

Residual heat display

7-segment display

Specification

Output, consumption

Hob

• Voltage: 220 – 240 V
• Total connected load: 7,4 kW
• 4 induction cooking zones with booster:
• 4 cooking zones 19,0 cm × 21,0 cm, 2,1 kW (3,7 kW)

Extractor fan

• Voltage: 220 – 240 V
• Total connected load: 7,4 kW
• Energy efficiency class A
• Average power consumption:: 38,8 kWh/year
• Fan efficiency class: A
• Grease filter efficiency class: A
• Noise max. Normal level ;
• Max. 69 dB(A)
• Fan output max. Normal level / Intensive level*:
• In extraction mode 484 m3/h / 553 m3/h
• In circulation mode 387 m3/h / 442 m3/h

* According to EU Regulation no. 65 / 2014 / fan power according to EN 61591

Design, comfort

Hob

• Frameless - Matt glass
• Smart Slider
• Touch Control
• 2 × combi induction
• Flexible linking – Any two cooking zones can be combined into one cooking zone
• Boost function for all induction cooking zones
• Grill function
• Electronic control in 10 power levels
• Digital display of cooking levels in white
• Residual heat display for each cooking zone
• Pot detection
• Child protection
• Timer – simultaneously adjustable for each cooking zone
• Countdown function
• Quick start function
• Recall function – Repeat the last settings
• Automatic safety switch-off
• Overflow detection
• Power management
• Flush-mounted installation possible
• Quick assembly system

Extractor fan

• With fan motor integrated into the hob
• Suitable for installation in a kitchenette or kitchen island
• Optional extraction or circulation mode (carbon filter required for circulation mode)
• 10-level fan output controllable via Touch Control
• 9 power levels + 1 intensive level
• Intensive level with automatic reset for extraction mode
• Automatic blower overrun
• Metal grease filter and carbon filter saturation indication by LED control lamp
• The device automatically blocks after 30 hours of operation for filter cleaning
• Powerful and quiet blower
• The ventilation system is activated automatically when a cooking zone is in use



Dimensions H × W × D

• Appliance dimensions: 20.1 × 78.0 × 52.0 cm
• Installation dimensions: 20,1 × 75,0 × 49,0 cm

Planning information:

• The fan motor is integrated directly into the hob
• Naber Compair Flow 150 air discharge, allowing for freedom in planning airflow
• Airflow can be routed in any direction
• Dishwashers, under-counter refrigerators, drawers etc. cannot be planned in the area of the exhaust air duct
• Min. cabinet width 800 mm (5IX 80290)
• Min. cabinet width 600 mm (5IX 60290)
• Min. worktop depth 600 mm (correspondingly deeper when planning in niche panelling)
• Worktop depth 600 mm (for flush-mountedplanning)
• Base height min. 100 mm (depending on the duct system used)
